The Sea Knight Helicopter : 3D Puzzle, Laser Cut, Scroll Saw, CNC Router, Template, Pattern DXF, CDR, SVG


The Sea Knight Helicopter 3D Puzzle brings the sleek design of this renowned military aircraft to life in impressive detail. Designed as a laser-cut CNC template, this intricate puzzle offers a rewarding and engaging assembly experience. Suitable for laser cutters, CNC routers, and plasma cutters. Included file formats are SVG, DXF, CDR, and PDF. Patterns are supplied in two standard sizes, usually 1/8th (.1250) and 3mm, but are scalable vectors, allowing you to adjust the pattern size to suit the thickness of your material. Scaling up will enlarge the finished model or shrink it if you scale down. Please see our Scale Calculator to make this task simple.



The “Sea Knight” Helicopter

The Boeing Vertol CH-46 Sea Knight is a medium-lift tandem rotor transport
helicopter. It is used by the Unite4d States Marine Corps to provide all-
weather, day-or-night assault transport of combat troops, supplies and
equipment. Additional tasks include combat support, search and rescue,
support for forward refueling and rearming points, CASEVAC and Tactical
Recovery of Aircraft and Personnel.
Canada also operated the Sea Knight, designated as CH-113, and operated them
in the SAR role until 2004. Other export customers include Japan, Sweden,
and Saudi Arabia. The commercial version is the BV 107-11, commonly referred
to simply as the “Vertol”. The CH-46 has a cargo bay with a rear loading
ramp that could be removed or left open in flight for expended cargo or for
parachute drops. An internal winch is mounted in the forward cabin and can
be used to pull external cargo on pallets into the aircraft via the ramp
and rollers. A belly sling hook, cargo hook, which is usually rated at
10,000 pounds could be attached for carrying external cargo. Although the
hook is rated at 10,000 pounds, the limited power produced by the engines
preclude the lifting of such weight. It usually has a crew of three, but
can accommodate a larger crew depending on mission specifics. For example,
a Search and Rescue variant will usually carry a crew of five to facilitate
all aspects of such a mission. A pintle-mounted Browning machine gun is
mounted on each side of the helicopteear for self-defense. Service in southeast
Asia resulted in the addition of armor with the guns. Known colloquially as
the “Phrog”, the Sea Knight has been used in all U.S. Marine combat and
peacetime environments since its introduction. As of 2011, it is still
regularly flown by the U.S. Marine Corps, its longevity as a reliable
airframe has led to such mantras as “phrogs phorever” and “never trust a
helicoptor under 30”.
collect your Sea Knight Helicopter today!

Hello and Thanks for shopping with makeCNC!
These 3D Puzzles are a Downloadable Product that have been Designed ready to cut on any CNC router or CNC Laser Machine.
They are supplied as ready-to-cut vector files in several formats for CNC Routers, Lasers, Plasma, Die Cutters and Scroll Saws are just of the few ways you can use these Patterns.

Basic slot sizes (Meaning your Material Thickness)

1/8 Inch or 1/4 Inch

Metric: Slot Size (Meaning your Material Thickness)

3mm or 6mm

1 x Color Assembly Guide.

Number of Parts:

Finished size of Model at 1/8th or 1/4 Inch

Finished size of Model at 3mm or 6mm

Approximate Size at 3mm

L= 432
W = 313
H = 135

Approximate Size at 1/8 inch

L = 17
W = 12.3
H = 5.3

Approximate Size of Largest Part

3.2 X 11 inches
82 X 280 mm

Approximate Part Number: 77

NOTE: Our 3D Puzzles can be built in different thicknesses.
Example: 1/8″ uses 1/8″ Plywood…1/4″ uses 1/4″ Plywood, etc.
As a rule, although the slots are set to fit the same sized tool, most
people will use a smaller bit size when cutting on a CNC Router.
