The Stirling Engine – Engine Series 3D Puzzle: The Stirling Engine – Engine Series 3D Puzzle brings to life the innovative design of the Stirling engine, known for its unique heat exchange mechanism. This puzzle is meticulously designed as a laser-cut CNC template, perfect for enthusiasts of mechanical engineering and sustainable technology. Suitable for laser cutters, CNC routers, and plasma cutters. Included file formats are SVG, DXF, CDR, PDF. The patterns are provided in two standard sizes, usually 1/8th (.1250) and 3mm, but are scalable vectors, allowing for the adjustment of the pattern size to suit the thickness of your material.
Description
PLEASE NOTE THIS IS A DIGITAL DOWNLOAD PRODUCT. NO PHYSICAL ITEM WILL BE SHIPPED !
The Stirling Engine – Engine Series
A Stirling engine is a heat engine that operates by cyclic compression and expansion of air or other gas the working fluid at different temperatures, such that there is a net conversion of heat energy to mechanical work. More specifically, the Stirling engine is a closed-cycle regenerative heat engine with a permanently gaseous working fluid. Closed-cycle, in this context, means a thermodynamic system in which the working fluid is permanently contained within the system, and regenerative describes the use of a specific type of internal heat exchanger and thermal store, known as the regenerator. The inclusion of a regenerator differentiates the Stirling engine from other closed cycle hot air engines.
Originally conceived in 1816 as an industrial prime mover to rival the steam engine, its practical use was largely confined to low-power domestic applications for over a century.
Stirling engines have a high efficiency compared to steam engines,being able to reach 50% efficiency. They are also capable of quiet operation and can use almost any heat source. The heat energy source is generated external to the Stirling engine rather than by internal combustion as with the Otto cycle or Diesel cycle engines. Because the Stirling engine is compatible with alternative and renewable energy sources it could become increasingly significant as the price of conventional fuels rises, and also in light of concerns such as depletion of oil supplies and climate change. This type of engine is currently generating interest as the core component of micro combined heat and power units, in which it is more efficient and safer than a comparable steam engine. However, it has a low power-to-weight ratio rendering it more suitable for use in static installations where space and weight are not at a premium.
Collect your Detailed & Very Impressive Engine Pattern today! It’s definitely a Must Have for Your Collection!
Hello and Thanks for shopping with makeCNC!
These 3D Puzzles are a Downloadable Product that have been Designed ready to cut on any CNC router or CNC Laser Machine.
They are supplied as ready-to-cut vector files in several formats for CNC Routers, Lasers, Plasma, Die Cutters and Scroll Saws are just of the few ways you can use these Patterns.
Basic slot sizes (Meaning your Material Thickness)
1/8 Inch or 1/4 Inch
Metric: Slot Size (Meaning your Material Thickness)
3mm or 6mm
1 x Color Assembly Guide.
Number of Parts:
Finished size of Model at 1/8th or 1/4 Inch
Finished size of Model at 3mm or 6mm
Approximate Size at 3mm
L= 305
W = 137
H = 124
Approximate Size at 1/8 inch
L = 12
W = 5.4
H = 4.9
Approximate Size of Largest Part
12 X 5.4 inches
305 X 137 mm
Approximate Part Number: 125
NOTE: Our 3D Puzzles can be built in different thicknesses.
Example: 1/8″ uses 1/8″ Plywood…1/4″ uses 1/4″ Plywood, etc.
As a rule, although the slots are set to fit the same sized tool, most
people will use a smaller bit size when cutting on a CNC Router.
