The Steam Engine – Engine Series : 3D Puzzle, Laser Cut, Scroll Saw, CNC Router, Template, Pattern, DXF, CDR, SVG

$9.95

The Steam Engine – Engine Series 3D Puzzle: The Steam Engine – Engine Series 3D Puzzle encapsulates the industrial revolution’s powerhouse, the classic steam engine. This puzzle is precisely designed as a laser-cut CNC template, ideal for enthusiasts of historical machinery and engineering. Suitable for laser cutters, CNC routers, and plasma cutters. Included file formats are SVG, DXF, CDR, PDF. The patterns are provided in two standard sizes, usually 1/8th (.1250) and 3mm, but are scalable vectors, allowing for the adjustment of the pattern size to suit the thickness of your material.

SKU: 2944 Category: Tags: , , , , , , , , , , , ,

Description

PLEASE NOTE THIS IS A DIGITAL DOWNLOAD PRODUCT.  NO PHYSICAL ITEM WILL BE SHIPPED !

The Steam Engine – Engine Series
A steam engine is a heat engine that performs mechanical work using steam as its
working fluid.
Steam engines are external combustion engines, where the working fluid is
separate from the combustion products. Non-combustion heat sources such as solar
power, nuclear power or geothermal energy may be used. The ideal thermodynamic
cycle used to analyze this process is called the Rankine cycle. In the cycle,
water is heated and transforms into steam within a boiler operating at a high
pressure. When expanded through pistons or turbines, mechanical work is done. The
reduced-pressure steam is then condensed and pumped back into the boiler.
In general usage, the term steam engine can refer to either the integrated steam
plants including boilers etc. such as railway steam locomotives and portable
engines, or may refer to the piston or turbine machinery alone, as in the beam
engine and stationary steam engine. Specialized devices such as steam hammers and
steam pile drivers are dependent on the steam pressure supplied from a separate
boiler.
The use of boiling water to produce mechanical motion goes back over 2000 years,
but early devices were not highly practical. The Spanish inventor Jerónimo de
Ayanz y Beaumont obtained the first patent for a steam engine in 1606. In 1698
Thomas Savery patented a steam pump that used steam in direct contact with the
water being pumped. Savery’s steam pump used condensing steam to create a vacuum
and draw water into a chamber, and then applied pressurized steam to further pump
the water. Thomas Newcomen’s atmospheric engine was the first commercial true
steam engine using a piston, and was used in 1712 for pumping in a mine.
Collect your Detailed & Very Impressive Engine Pattern today! It’s definitely a Must Have for Your Collection!

Hello and Thanks for shopping with makeCNC!

These 3D Puzzles are a Downloadable Product that have been Designed ready to cut on any CNC router or CNC Laser Machine.
They are supplied as ready-to-cut vector files in several formats for CNC Routers, Lasers, Plasma, Die Cutters and Scroll Saws are just of the few ways you can use these Patterns.

Basic slot sizes (Meaning your Material Thickness)

1/8 Inch or 1/4 Inch

Metric: Slot Size (Meaning your Material Thickness)

3mm or 6mm

1 x Color Assembly Guide.

Number of Parts:

Finished size of Model at 1/8th or 1/4 Inch

Finished size of Model at 3mm or 6mm

Approximate Size at 3mm
L= 389
W = 133
H = 94
Approximate Size at 1/8 inch
L = 15.3
W = 5.2
H = 3.7
Approximate Size of Largest Part
12.9 X 5.2 inches
328 X  mm 133
Approximate Part Number: 149

NOTE: Our 3D Puzzles can be built in different thicknesses.
Example: 1/8″ uses 1/8″ Plywood…1/4″ uses 1/4″ Plywood, etc.
As a rule, although the slots are set to fit the same sized tool, most
people will use a smaller bit size when cutting on a CNC Router.
